Description
QDL350 pcb up loader smt machine with Microcomputer control, stable and reliable.LCD screen display and menu interface to achieve the man-machine dialogue Alarm function.So can use standard magazine, strong commonality. According to the thickness of the PCB so set feeder lifting step distance. Automatic counting functions.Lifting distance adjustable according to PCB, 4 kinds of distance(10mm, 20mm, 30mm and 40mm) Loader configured with inner push board component, save the cost of buying PCB moving machine independently.Optional SMEMA port for communication between machines.
ModelQDL350Max applicable pcb size330*50~250mmSupport tray quantity2 piecesApplicable tray size350*320*565mmPCB transportation directionL→RTransportation speed10 m/sLifting step of material rack10,20,30,40Machine size1340*790*1200mmAir pressure0.6MpaSupply air pressure 5kgf/c㎡Power supplyAC220V 50/60HzRated Power200WMachine dimensions1680*765*1250mmNet weight230 kg
